Main features

1) Smart push-pull self-latching system.

2) Multicore types with 2 to 30 pins

3) Solder of PCB contacts(Straight or elbow)

4) High-density installation for space-saving

5) Ladder-like (half-moon shape) mortise, insulators with male and female contacts, Polarity orientation.

6) All direction shielding effect anti-electromagnetic interference

Component

1 Outer shell is made of copper alloy,chrome plated or nickel plated,

Outer shell may be made of stainless steel by special requirements.

2 Pin and jack are made of copper alloy, surface gold-plated.

3 Insulators was injection molding with high temperature, with good insulation properties of engineering plastics.

4 Sheath was injection molding with soft plastic,can be well protected cable.

5 Waterproof seal was molding with high temperature resistant silicone rubber.
